Trade Link

Catalogue No.	Specification
9220/F	Vibration resistance and drip proof engine room light fitting suitable for 2 x 20W. 230V. 50hz fluorescent tubes arranged side by side. The fitting made from Fibre body & provided with clear one piece acrylic cover is firmly secured to the housing with stainless steel toggles and fitted with rubber gasket to make totally insect free. The fitting provided with 2 nos. 20W copper polyester filled ballasts, power factor improvement capacitor, starter, lamp holder, 2 nos. cable entries, Brass glands etc. Duly wired up to a suitable connector with provision for earthing. 2 nos. MS brackets provided with lining for vibration mounting.
9220/MS	--do-- MS powder coated body
9240/F	Same as per 9220/F - suitable for 2 nos. of 40W tubes
9240/MS	--do-- MS powder coated body.

Specifications
9212/F	Vibration resistance and drip proof Engine room light fitting suitable for LED 24W. 240V. 50 hz The fitting made from Fiber body & provided with one piece hinged Polycarbonate milky cover is firmly secured to the housing with stainless steel toggles and fitted with rubber gasket to make totally insect free. The fitting with 24W. LED PCB with aluminium sheet for proper heat dissipation. The fitting provided with 2 nos. 12W LED Heavy Duty Electronic Driver with power factor imp., 2 nos. cable entries PG. cable glands etc. Duly wired up to a suitable connector with provision for earthing 2 nos. MS brackets for vibration mounting.
9212/AL	... do ... but fitting made from Aluminium sheet body duly powder coated.
9212/MS	... do ... but fitting made from CRCA body duly powder coated.
9209/F/AL/MS	Same as per 9212 but fitting with 2 nos. 9W. LED retrofit 2' tubes.
9218/F/AL/MS	Same as per 9209 but fitting with 2 nos. 18W. LED retrofit 4' tubes.

Catalog No.	Watt	Annual Power Consumption	Max. Lumens
9212 / F	24W	72 KW	2400 Im
9212 / AL	24W	72 KW	2400 Im
9212 / MS	12 W	72 KW	2400 Im
9209 / F / AL / MS	18 W	52 KW	1760 Im
9218 / F / AL / MS	36W	104 KW	3500 Im

Marine LED Vibration Proof Light Fitting
