Trade Link

Catalogue No.	Specification
CAT. NO. 2690	Cast Aluminium body light fitting with clear toughened front glass with Aluminium ring with rubber gasket fitting with Aluminum polished reflector and MS bracket for movement and fixing the fitting. Porcelain ES (screw type) lamp holder. Suitable up to 100W. lamp.
CAT. NO. 2691	--do-- Suitable up to 200W. lamp.
CAT. NO. 2692	--do-- Suitable up to 300W. lamp
CAT. NO. 2693	--do-- Suitable up to 500W. lamp

Catalog No.	Watt	Annual Power Consumption	Max. Lumens
4001	30 W	90 KW	2700 Im
4002	45 W	135 KW	4430 Im
4003	60 W	180 KW	5920 Im
4004	80 W	240 KW	7930 Im
4005	100 W	305 KW	9780 Im
4006	150 W	460 KW	14730 Im
4010	200 W	580 KW	17600 Im
4011	250 W	750 KW	23050 Im

Specifications
4001	Die Cast Aluminium body LED Flood light fitting with clear toughened front glass with Die Cast Aluminium cover ring with rubber gasket. Fitting with Aluminium polished reflector, Fitting with MS bracket for Vertical movement and fixing the fitting. Suitable for 30W. 240V. LED with suitable Electronic Driver. Fitting in the line of IP 65 protection.
4002	Same as per above... But suitable for 45W. 240V.
4003	Same as per above... But suitable for 60W. 240V.
4004	Same as per above... But suitable for 80W. 240V.
4005	Same as per above... But suitable for 100W. 240V.
4006	Same as per above... But suitable for 150W. 240V.
4010	Same as per above... But suitable for 200W. 240V.
4011	Same as per above... But suitable for 250W. 240V.

Marine LED Flood Light Fitting
