Marine Bulkhead Fitting





CAT. NO. 1142

CAT. NO. 1144

CAT. NO. 1146

Products Details

Catalogue No. Specification
1141 Oblong bulkhead fitting, cast Aluminium body with Aluminium hinged cover and locking arrangement oblong glass cover with protective SS wire guard, porcelain BC / ES lamp holder with 2 way connector. 2 nos. of conduit entries at top and bottom
1142 Same as per 1141 - not hinged type. Aluminium cover fix up with 4 nos. of screws. 2 nos. Cable entries opposite side with brass cable glands. Suitable up to 100W lamp.
1342 --do-- cast Brass body.
1144 Cast Aluminium body emergency use bulkhead light fitting with clear glass and Aluminium body frame. Brass SBC lamp holder for 25W. 24V. lamp. 2 nos. Cable entries with plastic cable glands.
1344 --do-- cast Brass body.
1146 Cast Aluminium body with Aluminium frame with opal acrylic shade. Decorative type. fitting with Brass SBC lamp holder for up to 25W lamp. Mainly in emergency use. 2 nos. Cable entries with 2 nos. Brass cable glands.
1346 --do-- cast Brass body.

LED BULKHEAD LIGHT FITTINGS

CAT. NO. 1106

CAT. NO. 1115/AL

Products Details

1115/AL Die cast Aluminium body with Die cast Aluminium cover fix up with 4 nos. of screws Oblong shape milky polycarbonate shade with rubber gasket and protective S.S. wire guard. 2 way connector, 2 nos. cable entries opposite side with PG cable glands. S.S. hardware. Fitting for 15W. 240V. LED with Suitable Electronic LED Driver Fitting in the line of IP 65 protection.
1115/BR Same as per Above ... But with Cast Brass body
1106/AL Surface / Recess type Die Cast Aluminium body with Die Cast Aluminium frame with Opal Polycarbonate shade. Decorative type LED Fitting with 2nos. cable entries with 2 nos. PG cable glands opposite side. S.S. hardware. Fitting for 6W. 24V. LED with Suitable Electronic Circuit. Fitting in the line of IP 55 protection. Fitting use Mainly in emergency. (Available in 110V / 240V also).
1106/BR Same as per Above ... But with Cast Brass body

Products Specifications


Catalog No. Watt Annual Power Consumption Max. Lumens
1115 / AL 15 W 45 KW 1500 Im
1115 / BR 15 W 45 KW 1500 Im
1106 / AL 06 W 18 KW 600 Im
1106 / BR 06 W 18 KW 600 Im
